i-Formatics

ELITE NEX White W500W 80Plus

Name: ELITE NEX White W500W 80Plus
Brand: i-Formatics
Price: 2950.00 MUR
Availability: InStock

Rs 2,950.00 MUR

Sale Sold out

Model MPW-5001-ACBW-B

ATX Version ATX 12V Ver. 2.41

PFC Active PFC

Input Voltage200-240V

Input Current4A

Input Frequency50-60Hz

Dimensions (L x W x H)140 x 150 x 86 mm

Fan Size120mm

Fan BearingSleeve Fan

Efficiency≥ 85% @ Typical Load

ErP 2014 Lot 3Yes

Operating Temperature0-40°C

Power Good Signal100 - 500 ms

Hold Up Time≥10ms at 100% load

MTBF>100,000 Hours

ProtectionsOVP / OPP / SCP / UVP / OTP / Inrush Protection

RegulatoryTUV, cTUVus, CE, FCC, CCC, EAC, UKCA

ATX 24 Pin Connectors1

EPS 4+4 Pin Connectors1

SATA Connectors5

Peripheral 4 Pin Connectors3

PCI-e 6+2 Pin Connectors2

Series Elite Series

Category500 to 750W

Modular non-modular

80 Plus Efficiency White

Form Factor ATX

Watts 500W
